AutoCAD® Templates

Current AutoCAD® templates are now available for all Lennox® commercial equipment. Download contains drawing templates in .dwg format that will work with all versions of AutoCAD (from 2004 to the most recent version). It also contains blocks and a Microsoft® PowerPoint (.pps). The .pps file has all the instructions on the file-naming convention and the layer definition.


Download includes:


  • Plan views

  • Elevation views of all sides of Lennox equipment

  • Dimensions

  • Clearance dimensions
